-- 8 --
1sxx02cw
WIRING DIAGRAM
WARNING !
STATIC ELECTRICITY can damage circuit
boards and electronic components.
S
SS
S Observe precautions for handling electrostatic
sensitive devices.
S
SS
S Use proper static--proof bags and boxes.
ESD
Component description
XT1 9 pole terminal block
PF20 Suppression circuit board
Q01 Main ON/OFF switch
K1 Main contactor
M1 Fan 230V 50Hz
M2 Pump motor, 230V 50Hz 0.2kW. Only machines with water cooler
C1 Capacitor, 6uF 250V, for reducing the speed of fan motor M1
C2 Capacitor, 3uF 400V. Start and run capacitor for fan motor M1
C3 -- C7 Suppression capacitors, 0,1uF 250V
C8 Snubber for K1 coil
H2 Orange indicating lamp, Error,overheating
H4 White indicating lamp, power supply ON
T1 Main transformer
TC1 Control power transformer
TC2 Transformer for CO2 heater. (an accessory, see an accessories listed in
user manual)
VB1 Rectifier
B1 Thermal switch. Protects the main transformer against excessive
temperature
B2 Thermal switch. Protects the chopper block against excessive temperature
B3 Thermal switch. Controls the speed of fan motor M1
CS Current sensor
R1 Resistor (pre--charging)
L1 Inductor
CB0 Control circuit board
