-- 6 --
1sxx02cw
Enclosure class IP 23
Application classification
Origo
TM
Mig 6502cw
Mains voltage 230/400--415/500 V 3∼ 50 Hz
230/440--460 V 3∼ 60 Hz
Permissible load at
60 % duty cycle
100% duty cycle
Mig/Mag: 650 A / 44 V; MMA: 650 A / 44 V
Mig/Mag: 500 A / 39 V; MMA: 500 A / 40 V
Setting range (DC)
MIG/MAG
MMA
Mig/Mag: 16A / 8V--650 A / 44 V
MMA: 16A / 8V--650 A / 44 V
Open circuit voltage Mig/Mag: 62V; MMA: 68V
Open circuit power
with cooling unit
in energy saving mode
(15 min after last welding)
670 W
870 W
60W
Power factor at maximum current 0,90
Efficiency at maximum current 76 %
Control voltage 42 V, 50/60 Hz
Dimensions lxwxh 830 x 640 x 835 mm
Weight
with cooling unit
222 kg
236 kg
Operating temperature --10 to +40˚C
Enclosure class IP 23
Application classification
Cooling unit
Cooling power 2500 W at40˚C temp. difference and flow
1,5l/min
Coolant 50 % water / 50% glycol
Coolant quantity 5,5 l
Maximum water flow 2,0 l/min
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP 23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
