Operation
36
Bench Top User’s Manual
FIGURE 6.4.SPECIMEN POWER CIRCUIT EXAMPLE
In this case, power to the specimen is shut off when the chamber stops.
FIGURE 6.5.TIME SIGNAL CIRCUIT EXAMPLE
In this case, power to customer circuit is shut off when the event is completed or the chamber stops.
Specimen
Power
Specimen
Switch Fuse
Power
source
Connector
Time
Signal
Control
Device
Switch Fuse
Power
source
Connector
Customer
Circuit
