ESPEC BTX-475 - Right Side; Test Area

Names and Functions of Parts
18
Bench Top User’s Manual
4.1.3 Right Side
FIGURE 4.3.RIGHT SIDE
4.1.4 Test Area
FIGURE 4.4.TEST AREA PARTS - SIZE 1 CHAMBER
Name Function/Use
(1) Power Connection Connection point for power cord.
(2) Refrigeration Room Access For maintaining refrigeration system.
(3) Circuit Breaker Access Access to electrical circuit protectors. Always unplug
power before opening this access.
Refrigeration Room
Access (2)
Circuit Breaker
Access (3)
Power Connection (1)
Air Circulator (5)
Dry Temperature
Sensor (6)
Return Air (3)
Shelf Support (2)
Chamber Lamp (4)
Wet Sensor / Wick
Arm or Solid State
Sensor (7)
Test Area (1)
