System Reference 13
Example:
Setting the A and B sides of one dimmer doubled circuit at a time is straightforward using
the A and B keys. It is possible to set ranges of dimmer doubled circuits. The following are
valid examples:
A side only
• 1 at 100 or 1A at 100 sets 1A to full
• 1 thru 6 at 100, 1 thru 6A at 100, 1A thru 6 at 100, or 1A thru 6A at 100 sets the A
sides of 1 through 6 at full
B side only
• 1B at 100 sets 1B to full
• 1B thru 6B at 100 sets B sides of 1 through 6 at full
Some A and some B sides
• 1 thru 6B at 100 or 1A thru 6B at 100 sets the A and B sides of 1 through 6 to full
• 1B thru 6 at 100 or 1B thru 6A at 100 sets 1B and the A sides of 2 through 6 to full
