72 CEM3 User Manual
Rack Configuration
Some possible rack configurations are listed below. Contact technical support with questions about
other rack configurations.
Configuring Local Mode
With the Rack/Local switch set to Local Mode, the PhaseAdept module can be configured from its front
panel. See
Rack/Local Switch
on
page 71
. In order to access the minimum scale dials, microUSB port,
and forward/reverse phase switches, you must remove two covers. Remove the screw and cover on the
front panel to access the forward/reverse phase switches. Access the top of the module to remove the
screw and cover for the minimum scale dials and microUSB port. See
Phase Adept Module Top View
with Covers Installed
on
page 73
,
Phase Adept Module Front View with Covers Installed
on
page 73
,
and
Phase Adept Module Front View with Covers Removed
on
page 73
.
Control Processor
Rack/Local
Switch
Setting
Module Configuration in Rack
120 V 230 V 277 V
CEM3 (v1.7.0+) Rack Mode LED10 ELED6
CEM3 Local Mode D20 ED15
CEM+
Local Mode D20 ED15
Rack Mode ELV10 HELV5
CEM Classic/ECEM Local Mode D20 ED15
MPE Local Mode D20
CMd/CMEd Local Mode D20 ED15
DRd Dimming Engine
Local Mode D20 ED15 AD20
Rack Mode ELV10 EELV6 AELV5
Note:
Older Unison DR enclosures may require rewiring in order to work with PhaseAdept
modules.
