70 CEM3 User Manual
Configuration
WARNING:
RISK OF ELECTRIC SHOCK! Failure to disconnect all power to the dimmer rack
before working inside could result in serious injury or death.
De-energize main feed to the dimmer rack and follow appropriate Lockout/
Tagout procedures as mandated by NFPA 70E. It is important to note that
electrical equipment such as dimmer racks can present an arc flash hazard if
improperly serviced. This is due to the high amounts of short-circuit current
available on the electrical supply to this equipment. Any work must comply
with OSHA Safe Working Practices.
Voltage Output
Control Input
Curve scales linearly
from min scale value
to 100%
Input Voltage
Min Scale
0 V
1%
100%
To Next Page
