26 CEM3 User Manual
Dimmer Output Diagram
This diagram illustrates the relationship between min scale, max scale, curve, threshold, and preheat
for the dimmer output from a CEM3 channel.
Min Scale Voltage
Max Scale Voltage
Output Voltage
Control Level
Threshold(%)
With Preheat Disabled
Output goes to zero
With Preheat Enabled
Output is at min scale
below threshold
100%
