ETC Sensor3 CEM3 - FDX2000 Vs. FDX3000 Dimmer Curve Comparison

FDX 3000 Dimmer Racks 67
FDX2000 vs. FDX3000 Dimmer Curve Comparison
Curves in FDX3000 reference voltage rather than power . Therefore the following table will help to
show the correlation between FDX2000 curve names and FDX3000 curve names.
.
FDX2000 Curve
English / German
FDX3000 Curve
English
Comment
1 = Linear (default) Square
Proportional to RMS power output
(FDX2000 Linear)
2 = Stage1 Stage 1 Built to match an old Siemens curve
3 = Stage2 Stage 2 Built to match an old Siemens curve
4 = Log Linear Proportional to RMS voltage output
5 = Fluor1 Fluor 1
6 = Fluor2 Fluor 2
7 = Pow/2 n.a. Obsolete
8 = 10% n.a. Obsolete
9 = VIP90 VIP
10 = ANDI ANDI
n.a Mod-Square (Default)
n.a Mod-Linear
n.a Sensor 2.0 Older mod square law
