System Reference 15
Setup
Commonly used features found here include:
• changing dimmer, rack, and network settings
• enabling control ports
• changing operating mode
• upgrading software or backing up the rack configuration
• changing curve and firing mode
Field Description
Dimmers
View and adjust the settings for any circuit in any rack connected to the
network. See
Dimmer Property Definitions
on
page 17
.
Rack
View and adjust the settings for the host Sensor3 rack. See
Rack Property
Definitions
on
page 20
.
Circuit Assignment
Assign the space, circuit number, and module type for any circuit slot in the
rack. You can auto assign or manually edit the options for any circuit.
For single and half-density modules such as the D20F, select Edit Circuit
Layout to adjust circuit numbering before you perform final patch updates.
Patching
Edit the patch and functionality for any port (DMX or sACN). See
Patching
on
page 34
.
Network
Set up and edit network properties for the CEM3. See
Setting Up CEM3 on
the Network
on
page 35
.
File Operations
Save configurations, load configurations, or upgrade CEM3 software using
either a USB memory device or an FTP server. See
Saving or Uploading Files
and Firmware
on
page 30
.
Panic
Record a panic look and set the specific details (such as fade and delay
times) for when a panic look is executed. See
Setting Up Panic
on
page 32
.
Time/Date
Set the rack’s time and date, or switch between automatic or manual time
setting.
Quick Setup
Quickly set up the rack configuration. For more information see
Performing
a Quick Setup
on
page 4
.
UI Preferences
Adjust various settings regarding the user interface. See
UI Preferences
on
page 16
.
