ETC Sensor3 CEM3 - Page 79

PhaseAdept Dimmer 73
Screw securing cover for min scale
dials and microUSB port
Phase Adept Module Top View with Covers Installed
Cover for min scale dials and
microUSB port
Screw securing cover for
forward/reverse phase switches
Phase Adept Module Front View with Covers Installed
0
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
Phase Adept Module Front View with Covers Removed
Bottom dimmer
min scale dial
Top dimmer
min scale dial
MicroUSB port
Forward/reverse phase switches
