18 CEM3 User Manual
Control Settings
Curve
The current operating curve for the dimmer. Options are: Square,
Mod-Square, Linear, Mod-Linear, and more. See
Dimmer Curves
on
page 21
for a complete listing of curves and their
descriptions.
Threshold%
In switched mode the threshold value defines the control
percentage at which the output turns on. In dimmed mode, the
threshold defines the level at which preheat is applied. See
Dimmer Output Diagram
on
page 26
for an illustration of how
threshold works with other dimmer properties.
On Level%
Latch-Lock only. The control level range (as percentage) that
causes the On Time to start counting down. Ranges available in
10% increments. Default is 41–50%.
See
Latch-Lock
on
page 7
.
Off Level%
Latch-Lock only. The control level range (as percentage) that
causes the Off Time to start counting down. Ranges available in
10% increments. Default is 81–90%.
See
Latch-Lock
on
page 7
.
On Time (sec)
Latch-Lock only. The time that a level must be maintained before
a circuit is switched on. Available range is 1–360 seconds.
Default is 5 seconds. See
Latch-Lock
on
page 7
.
Off Time (sec)
Latch-Lock only. The time that a level must be maintained before
a circuit is switched off. Available range is 1–360 seconds.
Default is 5 seconds. See
Latch-Lock
on
page 7
.
Patching
DMX A The DMXA channel to which the circuit is patched.
DMX A 16-Bit
Control whether the circuit receives 16-bit data from DMX A.
Options are Yes or No (Default = No).
DMX B The DMXB channel to which the circuit is patched.
DMX B 16-Bit
Control whether the circuit receives 16-bit data from DMX B.
Options are Yes or No (Default = No).
sACN
The sACN channel to which the circuit is patched. Displayed as
either universe/channel or absolute, based on UI Preference
settings (see
UI Preferences
on
page 16
).
sACN 16-Bit
Control whether the circuit receives 16-bit data from sACN.
Options are Yes or No (Default = No).
Dimmer Setup
screen
Submenu
(if applicable)
Definition
