60 PISA-E11 User`s Manual
Super IO Device
Phoenix-Award BIOS CMOS Setup Utility
Super IO Device
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Serial Port 2
[2F8/IRQ3]
UART Mode Select
[Normal]
x RxD , TxD Active
Hi, Lo
x IR Transmission Delay
Enabled
x UR2 Duplex Mode
Half
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x EPP Mode Select
EPP1.7
x ECP Mode Use DMA
3
PWRON After PWR-Fail
[Off]
Item Help
Menu Level ►
↑↓← → ：Move Enter: Select +/-/PU/PD: Value F10:Save Esc: Exit
F1:General Help F5:Previous Value F6:Fail-Safe Defaults F7:Optimized Default
Onboard Serial Port 1
Select an address and corresponding interrupt for the first serial
ports.
The choice: Disable, 3F8/IRQ4 (default), 2F8/IRQ3, 3E8/IRQ4,
2E8/IRQ3, Auto.
Onboard Serial Port 2
Select an address and corresponding interrupt for the second serial
ports.
The choice: Disable, 3F8/IRQ4, 2F8/IRQ3 (default), 3E8/IRQ4,
2E8/IRQ3, Auto.
