UART Mode Select
This item allows you to select which mode for the Onboard Serial
Port 2.
The choice: IrDA, ASKIR, Normal (default)
If UART Mode Select is IrDA and ASKIR will show:
Phoenix-Award BIOS CMOS Setup Utility
Super IO Device
Onboard Serial Port 1
[3F8/IRQ4]
Onboard Serial Port 2
[2F8/IRQ3]
UART Mode Select
[IrDA]
RxD , TxD Active
[Hi, Lo]
IR Transmission Delay
[Enabled]
UR2 Duplex Mode
[Half]
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[SPP]
x EPP Mode Select
EPP1.7
x ECP Mode Use DMA
3
PWRON After PWR-Fail
[Off]
Item Help
Menu Level ►
↑↓← → ：Move Enter: Select +/-/PU/PD: Value F10:Save Esc: Exit
F1:General Help F5:Previous Value F6:Fail-Safe Defaults F7:Optimized Default
RxD, TxD Active
The choice:
IR Transmission Delay
The choice: Disabled, Enabled (default).
UR2 Duplex Mode
The choice: Full, Half (default).
UART Mode Select
IrDA ……[ ]
ASKIR ……[ ]
Normal …..[ ]
: Move Enter: Accept ESC: Abort
UART Mode Select
Hi, Hi ……[ ]
Hi, Lo ……[ ]
Lo, Hi …..[ ]
Lo, Lo …..[ ]
: Move Enter: Accept ESC: Abort
