62 PISA-E11 User`s Manual
Onboard Parallel Port
This item allows you to determine onboard parallel port controller
I/O address setting.
The choice: 378/IRQ7 (default), 278/IRQ5, 3BC/IRQ7, Disabled.
Parallel Port Mode
The choice: SPP (default), EPP, ECP, ECP+EPP, Normal.
Sets the parallel port to function as a Standard Parallel
Port. This is the default (and slowest) option.
Sets the parallel port to Enhanced Parallel Port mode.
Sometimes also called "Bi-directional"
Sets the parallel port up as an Enhanced Capabilities
Port. This setting requires the use of a DMA channel
EPP Mode Select
Select EPP port type 1.7 or 1.9.
The choice: 1.7 (default), 1.9
ECP Mode Use DMA
If your system supports ECP parallel port mode and you have the
port set to use ECP, you must use this setting to assign a DMA
channel for use by the port.
The choice: DMA1, DMA3 (default).
PWRON After PWR-Fail
When power fails, you can select power ON or Off or Former status.
The choice: Off (default), On, Former-Sts.
