PISA-E11 User`s Manual 63
Onboard Serial Port 3
This is used to select an I/O address for the onboard serial port 3.
The choice: Disabled, 3F8, 2F8, 3E8 (default), 2E8.
Serial Port 3 Use IRQ
This is used to select an IRQ for the onboard serial port 3.
The choice: IRQ3 (default), IRQ4, IRQ5, IRQ7, IRQ10, IRQ11.
Onboard Serial Port 4
This is used to select an I/O address for the onboard serial port 4.
The choice: Disabled, 3F8, 2F8, 3E8, 2E8 (default).
Serial Port 4 Use IRQ
This is used to select an IRQ for the onboard serial port 4.
The choice: IRQ3, IRQ4 (default), IRQ5, IRQ7, IRQ10, IRQ11.
Watch Dog Timer Select
The choice: Disabled (default), Enabled.
