PISA-E11 User`s Manual 71
Reset Configuration Data
Default is disabled. Select Enabled to reset Extended System
Configuration Data (ESCD) when you exit Setup if you have installed a
new add-on and the system reconfiguration has caused such a
serious conflict that the OS cannot boot.
The choice: Enabled, Disabled (default).
Resources Controlled By
BIOS can automatically configure all the boot and Plug and Play
compatible devices. If you choose Auto, you cannot select IRQ DMA
and memory base address fields, since BIOS automatically assigns
them.
The choice: Auto (ESCD) (default), Manual.
If Resources Controlled By is Manual, you can choice IRQ Resource:
Phoenix-Award BIOS CMOS Setup Utility
PnP/PCI Configuration
**PCI Express relative items**
↑↓← → ：Move Enter: Select +/-/PU/PD: Value F10:Save Esc: Exit F1:General Help
F5:Previous Value F6:Fail-Safe Defaults F7:Optimized Default
