Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
16
(translation of the original operating instructions) MAN20001587-01-02/23
The following applies to inactive guard lock monitoring:
Important!
Ì From the assured release distance S
ar
, the safety outputs are safely shut down. To achieve
the assured release distance S
ar
, the actuator must be pulled completely out of the switch
head.
Ì To achieve the assured operating distances S
ao
, the actuator must be inserted completely
into the switch head.
Fig. 1: Front (A) and side (B, C) mounting
Fig. 2: Actuator alignment
A
C
B
