MAN20001587-01-02/23 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
EN
Fig. 3: Installation example
Fig. 4: Maximum actuator deection and maximum center offset
2 x M5
(6 Nm)
M5 (6 Nm)
M5 (3 Nm)
r ≥ 200
2 2
3,5°
3,5°
6°
6°
m = max. ± 2 mm
m
m
