AUDIO | VIDEO MEDIA CONTROLLER
USER GUIDEEuControl
48
6.1 Surfaces
The Surfaces tab shows all Artist media controllers on your network and those
connected to your instance of EuControl.
Figure 6-2 Surfaces tab
All Surfaces
All Surfaces shows all Artist media controllers on the network. A device shown in
light gray is already connected either to your own or another instance of EuCon-
trol running on a different workstation. In both cases, it is not selectable.
My Surfaces
My Surfaces shows the Artist media controllers connected to your instance of Eu-
Control. There can be one MC Control and up to four MC Mixes in the My Surfaces
list, linked into a single large surface.
The top-to-bottom order corresponds to the left-to-right order of the surfaces,
respectively. The leftmost surface has fader strip 1. Use the and buttons
to reorder the list.
Each Artist media controller can be renamed by double-clicking the existing name
and typing a new name.
