fig_2_3
fig_2_4
fig_2_5
11
Moreover:
DO NOT move the flow meter with the lifting device without the original packaging or without the help
of an appropriate support, ensuring the required stability.
2. GENERAL PRECAUTIONS
THE JUNCTION BOX ON THE
SENSOR IS DESIGNED TO BE IP68
PROTECTED ONLY WHEN PROPERLY
CLOSED AND FULL TIGHTENED.
THE MANUFACTURER ACCEPTS NO
LIABILITY FOR IMPROPER CLOSING
CARRIED OUT BY THIRD PARTIES.
NOTE
Compact version
Separate version
IP67 (Nema 4X)
• possibility of immersion 1 meter;
• maximum immersion time 12 hours. Separate
version
IP67 Electronics (Nema 4x)
IP68 Sensor (Nema 4x)
• possibility of continuous immersion in 1.5
metres water column.
