11. TECHNICAL DATA
11.1 General features
Power MC608A: 90...264 Vac 12/24 Vac/dc
MC608B: On Battery Battery Life Expectancy T = 0/50°C (32/122°F) up to 10 years
MC608R: With rechargeable battery + 10W solar panel
Display Graphic LCD 128x64 pixels, display area 50x25mm, backlit with white light.
Contents of the programmable display
Keyboard Yes, 4 push buttons
Programming and
communication
With push buttons
Through IrCOM interface and laptop with dedicated software
Through Modbus USB cable and laptop with dedicated software
Communication RS485 Modbus RTU
HART communication optional
Optional communication with integrated GSM / GPRS module
Output signals Analog output active / passive 4…20 mA
AUX 24Vdc output 30mA max
Digital output for up to 1000 Hz pulse duty cycle up to 50% for instant flow only
positive positive negative
Programmable digital output for:
• Reverse Flow
• MAX flow th.
• Min flow th.
• MAX/MIN flow th.
• Dosage
• excitation energy
• stopped empty Pipe
Digital outputs in active frequency 0-10 kHz
All outputs are optically isolated. Digital outputs with a maximum capacity of 35V
dc 30mA.
Fields of
temperature
Ambient: -25 C° to 60 C°
Storage: -30 C° to 70 C°
Signal cables Euromag cables:
• CA22 - cables for sensors with 4 electrodes
• CA23 - cables for 2 or 3 electrode sensors
Consumption MC608A:
• Min 5W • Max 10W
