HIGH FREQUENCIES OF PULSES WILL
AFFECT BATTERY LIFE
NOTE
Calculation of the parameters (values must be re
considered according to the technical units of the
converter)
[[Vp=litres, Tp=secons, Q=litres/seconds]
Vp>Qmax*20Tp
Tp<Vp/20Qmax
• Pulse time on
Select the ON time duration of the pulse on a range
included between 1 and 1999 ms
• Reverse flow (off / on)
Acting on this function, in the case of negative flow,
the pulses from the pulse output will be enable/
disabled
• Enable pulse output
Select to disable the frequency output and activate
the pulse output (factory condition)
WITH MC608B SELECT AN ON TIME OF
NO MORE THAN 0.1 SECONDS (100MS)
CAUTION!
10.4.2 FREQUENCY OUTPUT
• Full scale freq.
Set the maximum frequency corresponding to the
full scale flow rate value.
Selectable range: 100 Hz … 10 KHz
• Enable freq. output
Select to disable the pulse output (which becomes
PWM, pulse width modulation) and set the
frequency output
10.4.3 PROGRAMMABLE OUTPUT
You can choose between one of the following
options for the programmable output:
• Enabled/disabled
• Reverse Flow
• MAX flow th.
• Min flow th.
• MAX/MIN flow th.
• Batching
• Excitation failure
• Empty Pipe
- MC608B or MC608R battery powered
