fig_813_7

fig_813_5

125

480

fig_821_1

fig_813_6.tif

EUROMAG | MC608 | TD210-1

www.euromag.com

MAKE SURE THE SENSOR IS INSTALLED IN THE PIPE WITH THE FLOW DIRECTION

ARROW ON THE HANDLES, IN THE DIRECTION CORRESPONDING TO THE FLOW.

NOTE

THE PIPE MUST BE ALWAYS FULL

NOTE

10DN 15DN

• Localization - Mechanics

- Overall dimensions

Orientation

in line with the centre

8.2 INSTALLATION

25 mm (1”) Minimum distance
