fig_10_2
47
10.3 PARAMETERS
Ka setup
Diameter Setup
Filters setup
• Flow cut off
• Damping
• Bypass
• Peak cut off
• Measure average
• Line frequency
Zero finder
Flow rate alarms
• MAX flow th.
• MIN flow th.
• Empty pipe th.
Empty Pipe th.
10.3.1 KA CHANGE
It allows to modify the KA calibration factor.
ONLY AUTHORIZED PERSONS CAN
MODIFY THE KA FACTOR. THE KA
FACTOR MUST BE EQUAL TO THE
SENSOR COUPLED;
CHECK ON THE RATING PLATE OF THE
FLOW METER
CAUTION!
10.3.2 DIAMETER CHANGE
Allow changing the diameter. In case of insertion
flow meter, please enter the actual real inner
diameter value of the pipe in this menu.
10. MENU DESCRIPTION
