16
EUROMAG | MC608 | TD210-1
www.euromag.com
PPBT+ MUT 1100J FIBREGLASS
Sensor Maximum operating pressure Pipe flange - Flange - Class
Max. allowable tightening
torques
[bar] [psig] flange class [Nm] [ftlb]
DN 40 ≤10 ≤145 DN 40 PN 16/40 25 13
DN 50 ≤10 ≤145 DN 50 PN 16/40 35 19
DN 65 ≤10 ≤145 DN 65 PN 16/40 35 19
DN 80 ≤10 ≤145 DN 80 PN 16/40 35 19
DN 100 ≤10 ≤145 DN 100 PN 16/40 45 24
DN 125 ≤10 ≤145 DN 125 PN 16/40 65 35
DN 150 ≤10 ≤145 DN 150 PN 16/40 85 45
DN 200 ≤10 ≤145 DN 200 PN 16/40 100 53
1 1/2” ≤10 ≤145 1 1/2” 150/300 25 13
2” ≤10 ≤145 2” 150/300 35 19
2 1/2” ≤10 ≤145 2 1/2” 150/300 35 19
3” ≤10 ≤145 3” 150/300 35 19
4” ≤10 ≤145 4” 150/300 45 24
5” ≤10 ≤145 5” 150/300 65 35
6” ≤10 ≤145 6” 150/300 85 45
8” ≤10 ≤145 8” 150/300 100 53
