EUROMAG | MC608 | TD210-1

www.euromag.com

RECOMMENDED INSTALLATIONS ( ) AND THOSE TO BE AVOIDED ( ):

• In this installation the sensor is full with liquid • The position on the left is correct, the other two

ARE NOT.

• DO NOT place the sensor close to any variation

in the path of the flow.

• This installation DOES NOT guarantee a full pipe

condition.

THE SENSOR MUST ALWAYS BE COMPLETELY FULL WITH LIQUID!

IMPORTANT NOTE
