Euronda Pro System E8 - Overall Space Required

E8_Aus_rev07 – 2021-02-02
15
5.2 OVERALL SPACE REQUIRED
Overall dimensions of the machine with door closed (fig. 5.2-1):
E8 24L
L = 460 mm
H = 455 mm
P = 615 mm
Overall dimensions of the machine with door open (fig.5.2-1):
E8 24L
L = 610 mm
H = 455 mm
P = 930 mm
Weight of the machine:
E8 24L
Empty: 47.5 kg. Maximum weight with full tank and maximum load: 61.5 kg
