2.4.1. Sync Outputs
Connect the six Sync outputs of the Master A 5601MSC unit to the A Sync inputs of the 5601ACO2.
Connect the six Sync outputs of the Master B 5601MSC unit to the B Sync inputs of the 5601ACO2.
Connect the Sync outputs of the 5601ACO2 to your plant distribution amplifier system.

To ensure proper signal detection and distribution, terminate each sync output
with 75
Ω
(for example at the input of a distribution amplifier). If a sync output is
double terminated or un-terminated (as may be the case when the signals are
directly connected to a patch panel), the 5601ACO2 will hunt for a good input
signal by switching back and forth between input A and B. The flashing LEDs
will indicate the Sync output at fault.
2.4.2. 10 MHz Output
Connect the 10 MHz output of the Master A 5601MSC unit to the A 10 MHz input of the 5601ACO2.
Connect the 10 MHz output of the Master B 5601MSC unit to the B 10 MHz input of the 5601ACO2.
Connect the 10 MHz output of the 5601ACO2 to your plant 10 MHz reference system.
2.4.3. Word Clock Output
Connect the Word Clock output of the Master A 5601MSC unit to the A Word Clock input of the
5601ACO2. Connect the Word Clock output of the Master B 5601MSC unit to the B Word Clock input
of the 5601ACO2. Connect the Word Clock output of the 5601ACO2 to your plant Word Clock
distribution amplifier system.
2.4.4. Unbalanced DARS AES1 and AES2 Outputs
Connect the unbalanced DARS, AES1 and AES2 outputs of the Master A 5601MSC unit to the A
DARS AES1 and AES2 inputs of the 5601ACO2. Connect the unbalanced DARS AES1 and AES2
outputs of the Master B 5601MSC unit to the B DARS, AES1 and AES2 inputs of the 5601ACO2.
Connect the DARS AES1 and AES2 outputs of the 5601ACO2 to your plant’s unbalanced AES
distribution amplifier system.
2.4.5. Balanced DARS, AES1, AES2 and Analog Audio Outputs
Connect the balanced DARS, AES1, AES2 and analog audio outputs of the Master A 5601MSC unit to
the A DARS, AES1, AES2 and analog audio input terminal strip of the 5601ACO2. Connect the
balanced DARS, AES1, AES2 and analog audio outputs of the Master B 5601MSC unit to the B DARS,
AES1, AES2 and analog audio input terminal strip of the 5601ACO2. Connect the DARS, AES1, AES2
and analog audio output terminal strip of the 5601ACO2 to your plant balanced AES and analog audio
distribution amplifier systems. The cables can be secured into the removable portion of the terminal
strips using a small screwdriver. The removable part of the terminal strip is then inserted into the rear
panel and secured using the hold down screws.
