Model 5601ACO2 Automatic Changeover Unit
Page 4-10 Revision 1.2 TECHNICAL DESCRIPTION
4.6.3. Voting Control
3) Voting Control – set which input channel pair is included in the voting pool. Note that item 25 is the
global enable for items 1 through 24. If 25 is set to Yes, then voting will be determined by the settings
of items 1 through 24. If it is set to NO, then all channel pairs are included except HD-SDI and SD-
SDI, which are determined by DIP switch 7 settings. See section
3.3.4.
---- 5601ACO2 Voting Control ----
(1) Sync 1
(2) Sync 2
(3) Sync 3
(4) Sync 4
(5) Sync 5
(6) Sync 6
(7) LTC 1
(8) LTC 2
(9) GPO 1
(10) GPO 2
(11) Ten MHz
(12) Word Clock
(13) ATG 1
(14) ATG 2
(15) Balanced AES 1
(16) Balanced AES 2
(17) Balanced DARS
(18) Unbalanced AES 1
(19) Unbalanced AES 2
(20) Unbalanced DARS
(21) TG 1-1
(22) TG 1-2
(23) TG 2-1
(24) TG 2-2
(25) TG 3-1
(26) TG 3-2
(27) TG 4-1
(28) TG 4-2
(29) Global enable individual channel voting.
(S) Save and exit
(X) Exit without saving
Please note: (29) Enable channel voting is a global enable. If this is not enabled,
then all the items from 1 to 28 are not valid, and act as if they are set to be included
