5700ACO
Automatic Changeover
Page 2 Revision 1.0
In the event of a changeover occurrence, it is necessary that all outputs on one 5700MSC-IP have the
same timing as those on the other. Identical timing for both 5700MSC-IPs is assured by locking both to
the same frequency and phase source (i.e. GNSS, or genlocking one 5700MSC-IP to the other).
Features
• Relay switches for all the system critical outputs from two 5700MSC-IP units
• 6 video/sync outputs
• 4 SD/HD/3G SDI test signal outputs
• 10MHz frequency reference*
• Word Clock output*
• Balanced and unbalanced DARS and 2 AES outputs*
• Balanced analog audio output*
• Linear time code outputs*
* Requires factory installed +AUX hardware option on 5700MSC-IP, IP Master Clocks are available at
extra cost.
• Automatic changeover is a voting system based on which source has the most valid signals and
that the good signals on the present master are also on the backup.
• Three switches behind the front panel select automatic, front panel or GPI activation of changeover
• 56 Front panel status LEDs show the health of each of the inputs
• 14 Front panel status LEDs show the operational modes of the changeover
• Hot swappable redundant power supply standard
• VistaLINK
®
capable offering remote monitoring and configuration capabilities via SNMP using the
model 9000NCP Network Control Panel or Evertz VistaLINK
®
PRO or other third party SNMP
manager software.
Balanced DARS / AES / Analog audio
