4.4.2. Coaxial Inputs and Outputs
Type Depends on signal connected from 5700MSC-IP
SD/HD/3G SDI, DARS, AES Audio, bi-level or tri-level sync, colour black, 10
MHz,
Word Clock
Number 16 groups each consisting of two inputs and one output
Connector BNC per IEC 60169-8 Amendment 2
4.4.3. Balanced DARS, AES1, AES2 and Analog Audio Inputs and Outputs
Type Depends on signal connected from 5700MSC-IP
Balanced DARS, AES3 and analog Audio
Number 5 groups each consisting of two inputs and one output
Connector Removable Terminal Strip
4.4.4. ACO General Purpose Inputs and Outputs
Inputs
Front Panel Single GPI Control Mode (DIP switch 1 Off)
GPI1 Master select in Manual GPI control mode
Low: Selects Master A
High: Selects Master B
GPI2 Not used
Front Panel Dual GPI Control Mode (DIP switch 1 On)
GPI1 Master select in Manual GPI control mode
Low: Selects Master A
GPI2 Low: Selects Master B
Outputs
GPO1 Low: Master A is selected (default when the 5700ACO has no power)
High: Master B is selected
GPO2 Low: Master A & Master B differ or PSU failure
High: Master A and B have equivalent signals
