5700ACO

Automatic Changeover

Automatic Changeover Revision 1.0 Page 15

GPO Pin

from

internal

circuit

10 K

Figure 2-4 : GPO1 Output Circuitry

+ 5 VDC

10 K ohm

GPO Pin

from

internal

circuit

10 ohm

Figure 2-5 : GPO2 Output Circuitry

* Requires factory installed +AUX hardware option on 5700MSC-IP, IP Master Clocks are available at

extra cost.
