EQX Server Manual
Revision 2.2 Page 27
4.3.2.1 Types of Buttons
The following is a list of buttons that are used to configure the Control Panel.
BUTTON Description
Panel lock
Locks all functionality of the local panel.
Locks
Allows access to the locks functionality.
System Salvo
This key type allows one of the system salvos (defined by the salvo combo box) to
be fired.
Enable
Inhibits any source key from being taken to a destination unless this button is held
down.
Take
This key takes the current source pre-selection to the current destination on all the
currently enabled levels. The button will display the currently routed source on the
lowest enabled level, unless a legend is given to this key.
Source
Takes this source to a currently selected destination.
Src Shift Up
Scrolls up and through the Source List
Src Shift down
Scrolls down and though the Source List.
Source Preset
This key changes the source that is routed to the pre-select. This key does not
change any destination on the system but is used when a take or level take key is
pressed. It will then take this pre-selection to the current destination.
Prev Preset
Source
This key decrements the source that is routed to the pre-select. This key does not
change any destination on the system but is used when a take or level take key is
pressed. It will then take this pre-selection to the current destination.
Next Preset
Source
This key increments the source that is routed to the pre-select. This key does not
change any destination on the system but is used when a take or level take key is
pressed. It will then take this pre-selection to the current destination.
Destination
Changes the currently selected destination.
Dst Shift Up
Scrolls up and through the Destination List.
Dst Shift Down
Scrolls down and through the Destination List.
Previous
Destination
Changes the current destination to the previous one defined in the name table.
Next Destination
Changes the current destination to the next one defined in the name table.
Record Snapshot
of matrix
Saves a snapshot of the current routing system route status.
Play Snapshot of
matrix
Recalls (re-takes) previously recorded snapshot of the current routing system route
status.
Primary menu
Allows access to a primary menu.
Secondary menu
Allows access to a secondary menu.
Last menu
Displays and navigates to the previously displayed menu.
Level
Toggles the level on/off to affect possible breakaways on subsequent takes.
Displays the level name.
Table 4-1: Button Description
