Excell EX2005 User Manual

41
04011210
EXCELL PRECISION CO., LTD
ZSME400000003
Setting value
Item Function
Para-
meter
Description
Default
0 As display
1 Gross only
2 Net only
3 As display (simple)
4 Gross (simple)
5 Net (simple)
6 Comparison + As display (simple)
7 Comparison +Gross (simple)
8 Comparison +Net (simple)
9 Tare
RS1- 01
RS2- 01
Transmit format
10
Totalised (Accu.) Weight and number of
transactions
0
0 Transmit continuous + command mode
1 Auto transmit + command mode
2 Manual transmit + command mode
3 Command mode
RS1- 02
RS2- 02
Transmit mode
4 MODBUS RTU mode
3
0 600
1 1200
2 2400
3 4800
4 9600
RS1- 03
RS2- 03
Transmit speed
5 19200
2
0 N, 8, 1 No parity, 8 data bits, 1 Stop bit
1 O, 7, 1 Odd parity, 7 data bits, 1 Stop bit
Parity
Bit length
Stop Bit
2 E, 7, 1 Even parity, 7 data bits, 1 Stop bit
2
0 N, 8, 2 No parity, 8 data bits, 2 Stop bit
1 O, 8, 1 Odd parity, 8 data bits, 1 Stop bit
RS1- 04
RS2- 04
Parity
Bit length
Stop Bit
2 E, 8, 1 Even parity, 8 data bits, 1 Stop bit
2
0 Open
1 1 time/sec.
2 2 time/sec.
3 5 time/sec.
RS1- 05
RS2- 05
Transmit times
4 10 time/sec.
0
RS1- 06
RS2- 06
Transmission
conditions
0 0 0 0 0 0
000000
RS1- 07
RS2- 07
Indicator poling
address
00
↓
99
When set to 0, Indicator addressing is not
used
0
Negative (Net Wt.)
Weight unstable
Overload (OL)
0 ⇒ transmit cont.
1 ⇒ Stop transmit
