 Data format
1. General Format
NET S T , G S , + 0 1 2 3 4 5 6 k g
GROSS S T , N T , + 1 2 3 4 . 5 6 g
TARE S T , T R , +0123456 t
+ OL O L , G S , + SP SP SP SP SP SP SP SP SP
- OL O L , G S , - SP SP SP SP SP SP SP SP SP
UNSTABLE
U S , G S , + 1 2 3 4 . 5 6 k g
CR LF
2. Totalised (Accu.) Format (RS1-01 / RS2-01=10)
Accu. Weight T W , +123456 . 7 8 9 k g
Accu. Wt. Over+ T W , + SP SP SP SP SP SP SP SP SP SP SP SP
Accu. Wt. Over - T W , - SP SP SP SP SP SP SP SP SP SP SP SP
Accu. Count T N , +01234567 8 9
Accu. Count over
T N , + SP SP SP SP SP SP SP SP SP SP
CR LF
3. Sample Format
Gross/Net or as
display + 1 2 3 4 5 6
Over load positive
+ SP SP SP SP SP SP
Over load negative
- SP SP SP SP SP SP
CR LF
4. Setpoint (1) + Simple Format (Gross/Net or as display)
+ 1 2 3 4 5 6 CR LF
bit 7 bit 6 bit 5
bit 4 bit 3 bit 2 bit 1 bit 0
bit 0 : Zero Band
bit 1 : Over
bit 2 : Under / Hi
bit 3 : SP1 / OK
bit 4 : SP2 / Lo
bit 5 : SP3
bit 6 : Discharge
bit 7 : Batch finished
