BCD Parallel Output Interface (OP – 02)
Setting value
Item Function
Parameter Description
Default
0 As display
1 Gross
bCd- 01 Data type
2 Net
0
0 Transmit continuous
1 Auto transmit
bCd- 02 Transmit mode
2 Manual transmit
0
0 Positive logic action
bCd- 03 Output Logic
1 Negative logic action
0
0 Positive logic action
bCd- 04
Data ready
Signal logic
1 Negative logic action
0
0 FFFFFF
bCd- 05 OL output code
1 999999
0
0 BCD Code
bCd- 06 Data code
1 Hex. Code
0
Analogue Current/Voltage Output Interface (Op - 03)
Setting value
Item Function
Parameter Description
Default
0 As display
1 Gross
AnL- 01 Data type
2 Net
0
0 Current output
AnL- 02 Signal output
1 Voltage output
0
AnL- 03 Weight in Lo 000000 ~ 999999 0
AnL- 04
Current / Voltage
in Lo
0.0 mA ~ 20.0 mA
or
0.0 V ~ 10.0 V
When the weight reaches the value of
that in AnL-03(the Max. weight is the
max setting value (refer to CSP-04 ),
the current / voltage(refer to AnL-02)
output is changed to that configured in
AnL-04
4.0
AnL- 05 Weight in Hi 000000 ~ 999999 300000
AnL- 06
Current / Voltage
in Hi
0.0 mA ~ 20.0 mA
or
0.0 V ~ 10.0 V
When the weight reaches the value of
that in AnL-05(the Max. weight is the
max setting value (refer to CSP-04 ),
the current / voltage(refer to AnL-02)
output is changed to that configured in
AnL-06
20.0
