External Parallel Input/Output Interface (Op-04 & Op-05)
 OP-04 Control I/O (4 in / 4 out) + Setpoint Input (BCD code)
PIN I/O Signal PIN I/O Signal
1 IN Code 100 20 IN Code 101
2 IN Code 102 21 IN Code 103
3 IN Code 104 22 IN Code 105
4 IN Code 106 23 IN Code 107
5 IN Code 108 24 IN Code 109
6 IN Code 1010 25 IN Code 1011
7 26
8 27 OUT OUT 1
9 OUT OUT 2 28 OUT OUT 3
10 OUT OUT 4 29 IN Vex
11 COM 2 30 COM 2
12 31
13 COM 1 32 COM1
14 IN IN 1 33 IN IN 2
15 IN IN 3 34 IN IN 4
16 35
17 36 IN Code 1
18 IN Code 2 37 IN Code 4
19 IN Code 8
 OP-05 Control I/O (8 in / 8 out)
PIN I/O Signal PIN I/O Signal
1 IN IN 1 20 COM 1
2 IN IN 2 21 COM 1
3 IN IN 3 22 COM 1
4 IN IN 4 23 COM 1
5 IN IN 5 24 COM 1
6 IN IN 6 25 COM 1
7 IN IN 7 26 COM 1
8 IN IN 8 27 COM 1
9 COM 1 28 COM 1
10 COM 2 29 COM 2
11 OUT OUT 1 30 COM 2
12 OUT OUT 2 31 COM 2
13 OUT OUT 3 32 COM 2
14 OUT OUT 4 33 COM 2
15 OUT OUT 5 34 COM 2
16 OUT OUT 6 35 COM 2
17 OUT OUT 7 36 COM 2
18 OUT OUT 8 37 COM 2
19 IN Vex
