Test Setup - Test Configurator, Timer, and System
154 FTB-700G/800 Series
Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless)
WIS Button
Note: WIS is only available for 10GE WAN interface.
J0 Trace allows to set the J0 Trace value in 16 bytes format (default is
EXFO 10GigE).
J1 Trace allows to set the J1 Trace value in 16 bytes format allowing
up to 15 bytes (a CRC-7 byte will be added in front for a total of
16 bytes). Default is EXFO 10GigE.
Note: J0 and J1 values should be 7-bit T.50 suitable characters. The Padding drop
list from the message keyboard allows to select Null or Space to fill up the
J0 Trace and J1 Trace up to15 byte value. The Control Characters button
in the J0 Trace and J1 Trace message keyboard, allows to select the
required character. For more details on Control Characters, see page 39.
Path Signal Label (C2) byte is allocated to indicate the content of the
STS SPE, including the status of the mapped payload.
C2 (Hex.) Description
00 Unequipped
01 Equipped - Non-Specific
1A
a
a. Default value.
10 Gbit/s Ethernet (IEEE 802.3)
FE Test Signal, ITU-T 0.181
