Physical Interfaces and LEDs
NetBlazer 19
8.5G-11.3G (PORT #1)
8.5G-11.3G (PORT #1)
The 8.5G-11.3G PORT #1 can be used for the following test application and
optical rates:
Plug the SFP+ transceiver into the 8.5G-11.3G PORT #1 slot.
Note: Do not replace a SFP+ while the test is running to avoid distorting statistics.
First stop the test case, replace the SFP+ and then restart the test.
Application Rates
Transport OC-192/STM-64, OTU2, OTU1e, OTU2e, OTU1f, and OTU2f
Ethernet 10Gbit/s LAN and 10Gbit/s WAN
Packet Sync 10Gbit/s LAN
Fibre Channel 8X and 10X
Wireless CPRI: 9.8304 Gbit/s
WARNING
Use only EXFO supported transceivers. Refer to this product’s
technical specifications at www.exfo.com for the list of supported
transceivers. Using non-supported transceivers can affect the
performance and accuracy of the test.
