Test Setup - Test Configurator, Timer, and System
158 FTB-700G/800 Series
Interface (iSAM)
Interface (iSAM)
From the Test menu, tap Setup, Test Configurator, and the More button
from the Local block.
LINK
An arrow is used to indicate the status of the test link.
A green arrow indicates that the link is up.
A red arrow indicates that the link is down.
A gray arrow indicates awaiting incoming data to provide a status.
Interface/Rate or Port choices depend on the rates available on the
module.
For 10GE WAN, the test uses the WIS default values for J0, J1, and C2 as
defined in WIS Button on page 154.
Interface/Rate
10GE WAN
10GE LAN
1GE Optical
100M Optical
10/100/1000M Electrical
