Test Setup - Test Configurator, Timer, and System
NetBlazer 157
Interface (Ethernet, Packet Sync, Fibre Channel, and Wireless)
RX Frequency
Frequency (GHz) indicates the frequency of the input signal.
Offset (ppm) indicates the frequency offset between the standard rate
specification and the rate at the input signal.
Note: For both Frequency and Offset the following background colors are used.
Max Offset (ppm)
Negative indicates the maximum negative frequency offset between
the standard rate specification and the rate from the received signal.
Positive indicates the maximum positive frequency offset between the
standard rate specification and the rate from the received signal.
Background color Description
Green The frequency is in range.
Red The frequency is out-of-range. LOC is also displayed.
Gray Pending state.
