Test Results
396 FTB-700G/800 Series
Summary
RX Frequency
Note: RX Frequency is available for Through Mode test application on both ports
(Port 1 and Port 2).
Frequency (GHz) indicates the frequency of the input signal.
Offset (ppm) indicates the frequency offset between the standard rate
specification and the rate at the input signal.
Note: For both Frequency and Offset the following background colors are used.
Background color Description
Green The frequency is in range.
Red The frequency is out-of-range. LOC is also displayed.
Gray Pending state.
