Test Results
NetBlazer 449
Traffic - Flow Control
Pause Injection
Note: Pause injection is only available for Traffic Gen & Mon test application.
Packet Pause Time: Enter the pause time value to be transmitted in
Quanta or Microsecond (default is 100 Quanta).
Note: When entering a value in μs it will be rounded to the closest multiple of
0.0512 for 10 Gbit/s, 5.12 μs for 100 Mbit/s, 0.512μs for 1000 Mbit/s, and
0.0512μs for 10 Mbit/s, .
Inject button allows to generate the defined packet pause time.
Destination MAC Address check box, when selected (cleared by
default), enables and allows to set the destination MAC address. The
default destination MAC address is the control protocol multicast
address: 01:80:C2:00:00:01.
Interface
Range
Quanta μs
10 Mbit/s 0 to 65535 0 to 3355392
100 Mbit/s 0 to 65535 0 to 335539.2
1000 Mbit/s 0 to 65535 0 to 33553.92
10 Gbit/s 0 to 65535 0 to 3355.392
