Specications
ElectricalSystem
•ChargingSystem:ExternalAlternator
•ChargingCapacity:55amps
•BatteryType:BCIGroup26
•RecommendedMinimumBatteryCCA:540CCA
•BatteryVoltage:12Volt
•Polarity:NegativeGround
•Fuses:
–3TNV80FT:Three15ampbladetype;one
10ampbladetype
–3TNV88C:Three15ampbladetype;one25
ampbladetype
SafetyInterlockSystem
•Brakemustbeengaged,andmotioncontrol
leversout(neutrallock)tostartengine.(Itisnot
necessaryfortheoperatortobeintheseatto
starttheengine.)
•OperatormustbeinseatwhenPTOisengaged,
brakeisdisengaged,ormotioncontrolleversare
movedinorenginewillstop.
•Enginewillstopifeithertheleft,theright,or
bothleversaremovedfromneutrallockposition
whilebrakeisengaged.
EngineOverheatProtectionSystem
PTOwilldisengage,analarmwillsound,andabar
graphwilldisplaytheenginetemperaturewhenit
reachesanoverheatcondition.ThePTOwillnot
re-engageuntiltheenginehascooledandthePTO
switchismanuallyshut-offandre-engaged.
Note:Iftheenginecoolantlevelisbelowthe
indicatorlineontheoverowbottlewhenthe
engineiscold,thecoolanttemperaturegaugemay
notregistercorrectlyduringoperationand/or
thewarningbuzzermaynotsoundiftheengine
overheats.RefertoCheckEngineCoolantLevel
inMaintenance.
CoolingSystem
•Fan:Beltdriven
•CoolantLiquid:50/50solutionofwaterand
permanentethyleneglycolantifreeze.Theuseof
Havoline
®
XtendedLifecoolantisrecommended.
•CoolantCapacity:7quarts(6.6L)
OperatorControls
•SteeringandMotionControl:
Note:Motioncontrolleversareadjustableto
twoheights.
–Separatelevers,oneachsideoftheconsole,
controlspeedanddirectionoftravelofthe
respectivedrivewheels.
–Steeringiscontrolledbyvaryingtheposition
oftheleversrelativetoeachother.
–Movingmotioncontrolleversoutward(in
slots)locksthedrivesysteminneutral.
•PTOEngagementSwitch:Engageswetclutch(to
drivebelt)whichengagesmowerblades.
•ParkingBrakeLever:Engagesparkingbrake.
•DeckLiftSwitch(HydraulicCylinder):
–60and72InchDecks:Raises/lowersthedeck
tosetcuttingheight.
–96InchDeckModels:Raises/lowers
thecenterdecktosetcuttingheightand
folds/unfoldsthewings.
Seat
•Type:Deluxesuspension(adjustablespring
suspension)seatwithhighback,paddedip-up
armrests,andintegralsafetyswitch.Seatheight
remainsthesame.SeatIsolationSystemfor
reducedvibration,toenhancerideofstandard
seat.
•Mounting:Hingedtotiltupforaccessto
hydraulicreservoirandothercomponents.Held
intiltedpositionwithproprod.Adjustablefore
andaftseattrack.
•Armrests:Moldedadjustableip-uparmrests.
•SeatSafetySwitch:Integratedseatswitch.
Timedelayseatswitcheliminatesroughground
cut-outs.
HydrostaticGroundDriveSystem
•HydrostaticTransmission:Kanzaki.KPS18T
•WheelMotors:TwoHydro-Gear“H”Motors
•HydraulicOilType:ExmarkRubyTran
™
oil.
PartNo.135-2834
•HydraulicOilCapacity:15qt.(14.2L)
•HydraulicFilter:Replaceablecartridgetype.
21

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
