Exmark Lazer Z Series User Manual

Specications
P/N135-2252:10microns
•Speeds:
–3TNV80FT:
◊0-11.0mph(17.7km/hr)forward.
◊0-6.0mph(9.7km/hr)reverse
–3TNV88C:
◊0-12.5mph(20.1km/hr)forward.
◊0-7.0mph(11.3km/hr)reverse
•Drivewheelreleasevalvesallowmachinetobe
movedwhenengineisnotrunning.
DeckGearBox
OilType:SAE80W-90(APIGL-5)gearlube
Tires&Wheels
Drive—AllModels
Type
Pneumatic(Air-Filled)
Quantity
2
TreadSize
“Multi-TracC/S”
Size26x12.00-12
PlyRating
6
Pressure
18psi(124kPa)
FrontCaster—AllModels
Type
Semi-Pneumatic
Quantity
2
TreadSize
Smooth
Size15x6.00-6
CuttingDeck
•CuttingWidth:
–60inch(152.4cm)
–72inch(182.9cm)
–96inch(243.8cm)
•Discharge:SideorRear
•BladeSize:
–60inchDeck:20.5inches(52.1cm)(3ea.)
–72inchDeck:24.5inches(62.2cm)(3ea.)
–96inchDeck:24.5inches(62.2cm)(4ea.)
•BladeSpindles:Solidsteelspindleswith1.0inch
(25mm)I.D.bearings.
•DeckDrive:
–Wetclutchfromtransmissiontogearboxon
deckusingdriveshaft.
–BladesDrivenBy:
◊SideDischarge:One“B”Sectionbelt
(w/self-tensioningidler)fromgearbox
shaftondecktobladespindles.
◊72InchRearDischarge:One“BB”
Sectionbelt(w/self-tensioningidler)from
gearboxshaftondecktobladespindles.
◊96InchDeck:One“B”Sectionor5Vbelt
oncenterdeck.One“ A”Sectionbelton
eachwing.
•Deck:
–SideDischarge:Fulloatingdeckisattached
toout-frontsupportframe.Sixanti-scalp
rollersprovidemaximumturfprotection.
Deckdesignallowsforbagging,mulchingor
sidedischarge.
–RearDischarge:Fulloatingdeckisattached
toout-frontsupportframe.Deckdesign
allowsforreardischargeornishcut(reduced
discharge).Sidebumpersprovidemaximum
turfprotection.
◊72Inch:4anti-scalprollers
◊96Inch:13anti-scalprollers
•DeckDepth:
AllDecks:5.5inches(14.0cm)
•CuttingHeightAdjustment:
AllDecks:from1inch(2.5cm)to5.5inches(14
cm)in1/4inch(6.4mm)increments.
Pressingthedeckliftswitchcausesahydraulic
cylindertoraiseorlowerthedeck(andsidewings
–ifequipped).
•MulchingKit:Optional.
22

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
