Operation
glowsymbolontheREDLDUwilldisappearandthe
enginewillcrankwhenturnedto“START”.
Note:Thesystemwillallowtheunittostartwiththe
PTOswitchinthepulledout(up)position,butwill
notengagetheblades.ThePTOengagementswitch
mustberesettoengagethePTO.
HourMeter
LocatedontheinformationscreenoftheRED
EquippedLDUoftheRHconsole.
Thehourmeterrecordsthenumberofhoursthat
theenginehasrun.
HoursaredisplayedinEngine-Offscreenorinthe
EngineHourCountermenu(refertotheRED
EquippedUser’sGuide-DieselModelsformore
information).
DriveWheelReleaseValves
WARNING
Handsmaybecomeentangledintherotating
drivecomponentsbelowtheenginedeck,which
couldresultinseriousinjuryordeath.
Stopengine,removekey,allowallthemoving
partstostopbeforeaccessingthedrivewheel
releasevalves.
WARNING
Theengineandhydraulicdriveunitscanbecome
veryhot.Touchingahotengineorhydraulic
drivecomponentscancausesevereburns.
Allowtheengineandhydraulicdrivecomponents
tocoolcompletelybeforeaccessingthedrive
wheelreleasevalves.
Locatedoneachsideofthehydrostaticpump.
Drivewheelreleasevalvesareusedtoreleasethe
hydrostaticdrivesystemtoallowthemachinetobe
pushedwithouttheenginerunning.
Rotateeachbypassvalvecounterclockwiseoneturn
torelease;rotateclockwisetoresetsystem.DoNot
overtighten.DoNottowmachine.
g004644
Figure9
1.Rightbypassvalve
2.Leftbypassvavle
PTOEngagementSwitch
LocatedbehindtheREDEquippedLDUontheRH
console(seeFigure7).
Switchmustbe“ON”(pulledup)toengagethe
blades.Switchis“OFF”(pusheddown)todisengage
theblades.
TheLCDindicatorwillappearontheinformation
screenoftheREDEquippedLDUwhenthePTO
switchisdisengaged.
Note:EngaginganddisengagingthePTOswitch
changestheenginethrottlebetween“mow”and
“transport”mode.
Note:ThestarterwillcrankwiththePTOswitchin
the“ON”(pulledup)position;however,thesystem
willdisengagethePTOandaPTOreseterrorwill
occur.EngagingthePTOwillrequiretheoperatorto
resetthePTOswitchbyturningit“OFF”(pushed
down)andthenturningit“ON”.
Important:On96inchDecks:Thewingsmust
beunfoldedbeforethePTOcanbeengaged.
DeckLiftSwitch
LocatedonthebackpaneloftheRHconsole(see
Figure7).
•60and72inchDecks:
28

Exmark Lazer Z Series Specifications

General

Engine Brand	Kawasaki, Kohler
Engine Type	Air-cooled, 4-stroke, gasoline
Cutting Width	52 in, 60 in, 72 in
Deck Construction	Fabricated
Deck Material	Steel
Drive Type	Hydrostatic
Transmission	Hydrostatic
Forward Speed	Up to 12.5 mph
Reverse Speed	Up to 5 mph
Tires (Rear)	26 x 12-12 (depending on model)
Turning Radius	Zero-turn
Cutting Height	1.5-5 inches (adjustable)
Speed	Up to 12.5 mph
Warranty	5-year / 1, 500-hour (Engine warranty varies by manufacturer)
