SIS Command and Response Table for Input-Board-Specific Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Inputs on XTP CP 4i [XTP] Boards
XTP power
ATTENTION:
• Power over XTP (PoX) is intended for indoors use only. No part of a network that uses PoX can be routed outdoors.
• PoX est destiné à une utilisation en intérieur uniquement. Aucune partie d’un réseau qui utilise PoX ne peut être routée en extérieur.
NOTE:
• PoX is supplied by the XTP II CrossPoint 48 V power supply.
• XTP II CrossPoint 1600:
• Can power up to 28 total (input and output) endpoints at up to 364 watts.
• Is available with optional 48 V power supply redundancy.
• XTP II CrossPoint 3200:
• Can power up to 24 total (input and output) endpoints at up to 312 watts.
• No 48 V power supply redundancy is available.
• XTP II CrossPoint 6400:
• Can power up to 128 endpoints at up to 1664 watts.
• 48 V power supply redundancy is standard.
Enable or disable power to input
endpoint and report status
E
I
X^
*
X2#
POEC
}
PoecI
X^
*
X2#
*
X2$
*
X2%]
Enable or disable (
X2#
) remote power to
input
X^
. The endpoint is requesting
X2$
watts and the power status is
X2%
.
Example:
E
I1*1POEC
}
PoecI01*1*13*1
]
Enable remote power on input 1, which
is requesting 13 watts. The board is
providing power to the endpoint.
View input power status
E
I
X^
POEC
} X2#
*
X2$
*
X2%]
Enable or disable input power and
report status, all inputs
E
I
X2#
*POEC
}
PoecI00*
X2#
1
X2#
2
...
X2#
n
]
Each
X2#
is the enable or disable status of
an input, starting at 1. n is 16, 32,or 64.
View input power status, all inputs
E
IPOEC
} X2#
1
X2#
2
X2#
3
...
X2#
n
]
View XTP power usage
E
TPOEC
} X2^
*
X2&]
Show PoX wattage applied and the
status of the 48 V power supply.
Example:
E
TPOEC
}
450*0
]
The switcher is providing 45.0 watts
and the power supply is Ok.
Inputs on XTP CP 4i 3G Boards
AES digital audio channel selection
NOTE: Eight-channel audio is divided into two groups, each
consisting of two channel pairs (four channels). The table at
right shows the channels contained within each group.
Group 1 Group 2
Ch Pair 1 Ch Pair 2 Ch Pair 1 Ch Pair 2
Ch 1 Ch 2 Ch 1 Ch 2 Ch 1 Ch 2 Ch 1 Ch 2
Select channel
E
X^
*
X2*
AESC
}
Aesc
X^
*
X2*]
Select digital audio channel pair on
which audio will be embedded.
View selected channel
E
X^
AESC
}
X2*]
AES digital audio group selection
Select group
E
X^
*
X2(
AESG
}
Aesg
X^
*
X2(]
Select digital audio channel group on
which audio will be embedded.
View selected group
E
X^
AESG
}
X2(]
NOTE: X^ = Input number (for other than tie) 01 – 16, 32, or 64
X2# = Enable or disable for power 0 = Disable (default) 1 = Enable
X2$ = Amount of power requested 00 or 13 (watts)
X2% = Power status 0 = Unpowered endpoint 2 = Power available, disabled 4 = Fault
1 = Power provided to endpoint 3 = No power available, enabled
X2^ = Wattage Power usage in 0.1 watt increments. Example: 260 = 26.0 watts
X2& = Power supply status 0 = Ok 1 = Not Ok
X2* = AESC digital channel pair 1 (default) or 2
X2( = AESG digital channel group 1 (default) or 2
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 92
