Extron electronics XTP II CrossPoint Series User Manual

SIS Command and Response Table for Basic Matrix Switcher Commands (continued)
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
Read ties
NOTE: The & read tie command for RGB and the % read tie command for video can be used interchangeably on the matrix switchers.
Read RGB (video) output tie
X@
&
X!]
RGB input
X!
is tied to output
X@
.
Read video output tie
X@
%
X!]
Video input
X!
is tied to output
X@
.
Read audio output tie
X@
$
X!]
Audio input
X!
is tied to output
X@
.
Recall global input presets
NOTES:
• Save presets from the front panel (see Example 5: Saving a preset on page 47) or via the Save current configuration as a
global preset SIS command on page 111).
• If you try to recall a global preset that is not saved, the matrix switcher responds with the error code E11.
Recall a global input preset
X#
. Rpr
X#]
Command character is a period.
Example:
5.
Rpr05
]
Recall preset 5, which becomes the
current configuration.
SIS Command and Response Table for Input-Board-Specific Commands
The table that starts below shows commands that affect inputs only and, in general, apply
to installed input boards. Where a command does not apply to all input board types, the
valid board types are noted.
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional Description
EDID commands
NOTES:
• See table 9, on the next two pages for
X$
values.
• Leading zeroes are optional for the entry of the inputs (
X^
s) and EDID values (
X$
s). Leading zeroes are reported in the response.
Assign EDID data to an input
E
A
X^
*
X$
EDID
}
EdidA
X^
*
X$]
Assign an EDID value of
X$
to input
X^
.
Example
(XTP II CrossPoint 6400):
E
A7*70EDID
}
EdidA07*070
]
Assign an EDID value of 1280x768 at
60 Hz to input 7.
Example
(XTP II CrossPoint 3200):
E
A7*70EDID
}
EdidA07*070
]
Assign an EDID value of 1280x800 at
60 Hz to input 7.
Example
(XTP II CrossPoint 1600):
E
A7*70EDID
}
EdidA07*070
]
Assign an EDID value of 1680x1050 at
60 Hz to input 7.
Assign EDID data to all inputs
E
A*
X$
*EDID
}
EdidA00*
X$]
Assign an EDID value of
X$
to all inputs.
View EDID assignment
E
A
X^
EDID
} X$]
Save output 1 EDID to user
assigned slot
E
S
X$
EDID
}
EdidS
X$]
Save the output 1 EDID to location
X$
.
NOTE: For this command,
X$
is valid only in the range of 117 through 124 (XTP II CrossPoint 1600), 133 through 140
(XTP II CrossPoint 3200), or
165 through 172 (XTP II CrossPoint 6400).
Example
(XTP II CrossPoint 6400):
E
S165EDID
}
EdidS165
]
Save the output 1 EDID to user location 1.
Example
(XTP II CrossPoint 3200):
E
S133EDID
}
EdidS133
]
Save the output 1 EDID to user location 1.
Example
(XTP II CrossPoint 1600):
E
S117EDID
}
EdidS117
]
Save the output 1 EDID to user location 1.
NOTE: X! = Input number (for tie) 00 – 16, 32, or 64 (00 = untied)
X@ = Output number 01 – 16, 32, or 64
X# = Global preset number 01 - 32
X$ = EDID value (resolution and rate) See table 9 on the next two pages.
X^ = Input number (for other than tie) 01 – 16, 32, or 64
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Programming Guide 87
