By adding or removing I/O boards within certain rules that are detailed in Input and
Output Boards on page 14, you can expand and contract the switcher from a 4-input by
4-output matrix to up to:
XTP II CrossPoint 1600 — A 16-input by 16-output matrix
XTP II CrossPoint 3200 — A 32-input by 32-output matrix
XTP II CrossPoint 6400 — A 64-input by 64-output matrix
The matrix switchers can be remotely controlled via their rear panel Remote RS-232/RS-422
ports, their rear panel LAN port, and their front panel Configuration (USB) port by any of the
following:
A control system
A PC
An Extron MKP 2000 remote control panel
an Extron MKP 3000 remote control panel
(RS-232/RS-422 only) An Extron MCP 1000 remote control panel
(RS-232/RS-422 only) An Extron MKP 1000 remote keypad
Control can be via the Extron XTP Configuration Software, the Simple Instruction Set (SIS),
or HTML pages (LAN port control only). The SIS is a set of basic ASCII code commands
(see Programming Guide on page 76) that provide simple control through a control
system or PC. The built-in Web pages (see HTML Operation on page 119) can be
accessed via the LAN port using a Web browser such as the Microsoft
®
Internet Explorer
®
.
The matrix switchers are housed in rack-mountable, metal enclosures with mounting flanges
for standard 19-inch racks
XTP II CrossPoint 1600 — 5U high
XTP II CrossPoint 3600 — 10U high.
XTP II CrossPoint 6400 — 20U high.
The base XTP II CrossPoint 1600 ships with two internal power supplies on a single AC
connection that provide 12 V and 48 V. It can be ordered with two additional optional
redundant (12 V and 48 V) power supplies. The customer cannot install the redundant
power supplies.
The XTP II CrossPoint 3200 ships with three 12 V internal power supplies and one 48 V
power supply, on a single AC connection. The switcher can operate using two of the 12 V
supplies with the third as a hot backup. The fourth supply provides power over the XTP
connection to remote devices (Power over XTP [PoX]).
The XTP II CrossPoint 6400 has an attached AC power connector that can be plugged
into a standard North American 220 VAC, 60 Hz power power outlet or wired directly into a
junction box providing single phase 200-240 VAC, 50/60 Hz power by a licensed electrician.
The XTP II Crosspoint 6400 is pluggable type B equipment.
The 100 VAC to 240 VAC, 50-60 Hz power supplies in the XTP II CrossPoint 1600 and
XTP II CrossPoint 3200 provide worldwide power compatibility and reliability. Front panel
LEDs indicate good and failed status for each supply.
Endpoint Configuration
In an XTP system, the transmitters connected to the input boards and the receivers
connected to the output boards are known as “endpoints.”
When you configure an XTP system (consisting of an XTP II CrossPoint Matrix switcher and
its connected endpoints), connect a computer to the matrix switcher and configure the
endpoints from the matrix switcher. Do not connect the computer directly to the endpoint
for configuration when it is part of an XTP system.
XTP II CrossPoint 1600, 3200, and 6400 Switchers • Introduction 3
